差模电感
- 额定电流为0.3至10 A
- 直流至400 Hz频率
- 100 kHz至3 MHz共模谐振频率
- 双扼流圈配置
- 多种PCB安装选项 </ul
Features and Benefits
规定了3种不同的应用
Typical Applications
能源滤波
Technical Specifications
Operating voltage
250 VAC
Operating frequency
DC to 400 Hz
Surge current @ 10 msec
20 x I<sub>N</sub> @ 25°C
Temperature range (operation and storage)
-40°C to 125°C (40/125/56)
acc. IEC 60068-1
Flammability corresponding to
Housing UL 94V-0
Potting compound UL 94V-0
Ringcore coating UL 94V-0
Design corresponding to
UL 1283, IEC/EN 60938-1
Rated currents
0.5 to 4 A
0.5 to 4 A @ rated ambient temperature
Rated inductance
0.003 to 4 MILLIHENRY
0.003 to 3.6 mH
Typical electrical schematic
Approvals & Compliances
